VanPro-550/600/650

VanPro-550/600/650

VanPro-550/600/650
VanPro-550/600/650VanPro-550/600/650
CategoriesPVC Coated Fabric
AlbumView larger image
BrandTaimei
Life Time3 year
Weight550-700g/m²
Bese FabricPolyester
Thickness0.42-0.54mm
Roll Width (Max)2.5m
Roll Length (Max)20 - 800m
Surface FinishingPVC
Tear Strength-Warp100N/5cm
Tear Strength--Weft100-120N/5cm
Coating Adhesiion80N/5cm
Temp Resistance-30 to +70℃
Fire RetardentB1,B2 Level
TreatmentUV treated; Acrylic Lacquered
Printing CompatibilityPrinting Ready
Update Time2020-09-19
Detail Information

VanPro-550/600/650

This material is made to handle extreme outdoor conditions and heavy stress. Ideal for many other uses such as heavy duty bags, outdoor covers, play mats, outdoor shelter uses, the applications are endless. It could be the solution you are looking for outdoors or indoors!



Specifications:

MATERIAL DESCRIPTION
ITEM UNIT RESULT TEST STANDARD
Weight (+/-3%) g/m² 550 600 700 DIN EN ISO 2286-2
Bese Fabric Type Polyester Polyester Polyester DIN 60001
Yarn Denier 600*600 600*900 900*900 DIN EN ISO 2060
Fabric Count yarn/sq.inch 2*2 2*3 3*3 DIN EN 1049-2
Thickness mm 0.42 0.5 0.54 -
Roll Width (Max) m 2.5 2.5 2.5 -
Roll Length (Max) m 20 - 800 20 - 800 20 - 800 -
Surface Finishing Material PVC PVC PVC
Tensile Strength-Warp N/5cm 2200 2200 2300 DIN53354
Tensile Strength-Weft N/5cm 1400 1450 1450 DIN53354
Tear Strength-Warp N/5cm 100 100 120 DIN53354
Tear Strength--Weft N/5cm 100 120 120 DIN53363
Coating Adhesiion N/5cm 80 80 80 DIN53363
Temp Resistance -30 to +70 -30 to +70 -30 to +70 DIN EN 1876-2
Fire Retardent B1,B2 level is optional upon request
Treatment UV treated; Acrylic Lacquered upon request.
Color 16 standard color, and can be customized.
Printing Compatibility Printing Ready
Temp Resistance Special treatment to use under -40℃ (optional)
Note: The technical specifications contained herein are believed to be reliable, but no representations, guarantees or warranties of any kind are made regarding their accuracy or suitability of the material for particular applications.


Features:

  • Excellent UV-protection
  • Hign Tenacity Strength
  • Anti Mildew
  • Crack Resistant
  • Customized FR Standard
  • REACH Regulations Standard
  • Anti cold crac

Colors Available:

  • Black

  • White

  • Red

  • Orange

  • Dark Green

  • Dark Red

  • Blue

  • Grey

  • Green

Applications:

  • Truck Cover

    Can effectively protect your vehicle from harmful UV rays.
  • Trailer Cover

    Significantly reduces premature aging of trailer and helps maintain resale value.
  • Boat Covers

    Protect your marine investment from the damaging effects of sun
