LamiAd-340/500 Advertising Banner Fabric

Categories	PVC Tarpaulin Sheet
Brand	TAIMEI Tarpaulin Shade Fabric Manufacturer
Life Time	1-2 year
Weight	340-500g/m²
Bese Fabric	Polyester
Thickness	0.35-0.5mm
Roll Width (Max)	3.2/5.1m
Roll Length (Max)	20 - 800m
Surface Finishing	PVC
Tensile Strength-Warp	350-650N/5cm
Tensile Strength-Weft	250-550N/5cm
Temp Resistance	-30 to +70℃
Fire Retardent	B1,B2 level
Treatment	UV treated; Acrylic Lacquered
Printing Compatibility	Printing Ready
Update Time	Apr 27,2024

Detail Information

: LamiAd-440/500 Advertising Banner Fabric

Recyclable and is designed for long term durability. Comes recommended for both outdoor and indoor displays.

This option for can used in Outdoor & Indoor banners, exhibitions, displays, backdrops, murals, signage, hoarding, standees, Flags, Boards, Banners, hoardings, front and backlit banners and Wallpapers.

MATERIAL DESCRIPTION
ITEM	UNIT	RESULT			TEST STANDARD
Weight (+/-3%)	g/m²	340	440	500	DIN EN ISO 2286-2
Bese Fabric	Type	Polyester	Polyester	Polyester	DIN 60001
Yarn	Denier	200*300	300*500	500*500	DIN EN ISO 2060
Fabric Count	yarn/sq.inch	18*12	18*12	9*9	DIN EN 1049-2
Thickness	mm	0.35	0.44	0.5	-
Roll Width (Max)	m	3.2/5.1	3.2/5.1	3.2/5.1	-
Roll Length (Max)	m	20 - 800	20 - 800	20 - 800	-
Surface Finishing	Material	PVC	PVC	PVC	-
Tensile Strength-Warp	N/5cm	350	550	650	DIN53354
Tensile Strength-Weft	N/5cm	250	450	550	DIN53354
Tear Strength-Warp	N/5cm	120	160	200	DIN53354
Tear Strength--Weft	N/5cm	80	140	220	DIN53363
Coating Adhesiion	N/5cm	30	35	35	DIN53363
Temp Resistance	℃	-30 to +70	-30 to +70	-30 to +70	DIN EN 1876-2
Fire Retardent	B1,B2 level is optional upon request
Treatment	UV treated; Acrylic Lacquered upon request.
Color	16 standard color, and can be customized.
Printing Compatibility	Printing Ready
Temp Resistance	Special treatment to use under -40℃ (optional)
Note: The technical specifications contained herein are believed to be reliable, but no representations, guarantees or warranties of any kind are made regarding their accuracy or suitability of the material for particular applications.
