PP Monofilament Woven Fabric (Sulzer Looms)

PP Monofilament Woven Fabric (Sulzer Looms)

PP Monofilament Woven Fabric (Sulzer Looms)

PP Monofilament Woven Fabric (Sulzer Looms)

CategoriesPP Woven Fabric
BrandTAIMEI Tarpaulin Shade Fabric Manufacturer
ModelWF-P014
MaterialPolypropylene
ColorBlack, White, Milky
Density8x8 to 12x12
Yarn1000D to 2000D
ApplicationGeotextile
Weight110-130gsm
Update TimeApr 21,2024
Detail Information

Introduction

Our PP Monofilament Woven Fabric are manufactured on Sulzer Looms machine.

Woven Monofilament Geotextiles, often referred to as Filtration Geotextiles, are manufactured from extruded polypropylene monofilaments woven to create a very dimensionally stable, highly permeable geotextile. As filters, Woven Monofilament Geotextiles have superior resistance to soil and biological clogging. As separators and stabilizers, they allow water to freely pass while preventing contamination of base material and adding tensile elements to soil and fill material.

Monofilament Geotextiles are primarily used to provide filtration underneath materials such as gravel, rip-rap, large stone blocks, Geo-Cell, interlocking blocks, paving bricks, or other types of erosion protection material. They function by restricting soil particles but allowing liquid and gases to easily pass through them.



Material Specification:

Material Specification:

Property 20-15 30-22 40-28 50-35 60-42 80-56 100-70
Break Strength KN/m≥(LD) 20 30 40 50 60 80 100
Break Strength KN/m≥(TD) 15 22 28 35 42 56 70
Break Elongation %≤(LD,TD)
28
Trapozoidal Tearing Strength KN≥(LD) 0.3 0.45 0.5 0.6 0.75 1.0 1.2.
Burst Strength KN≥ 1.6 2.4 3.2 4.0 4.8 6.0 7.5
Vertical Permeability Coefficient cm/s
10-1-10-3
Sieve Size (O95.)mm
0.08-0.5
Mass Weight g/m2 120 160 200 240 280 340 400
Variation% ±10

Advantages:

  • Reduces the required aggregate thickness in unpaved roads.
  • Extends road and railway life.
  • High tensile strength and durability.
  • Cost-effective environmental alternative to traditional construction materials.
  • Easy to install.
  • Helps speed-up construction with short-term reinforcement of the base.

Common Applications:

  • Soil separation
  • Filtration
  • Erosion & sediment control
  • Sub-grade stabilization
  • Protection for geomembrane liners
  • Covers & tarps
  • Shoreline revetment systems
  • Hard armour underlayment
  • Subsurface drainage
  • Containment
  • Temporary liners
  • Landfills

Colors Available:

  • Black

  • White



Applications:
