Tufflex-Tarp Fabric
Tufflex-Tarp Fabric
Categories | PVC Tarpaulin Rolls |
---|---|
Brand | TAIMEI Tarpaulin Shade Fabric Manufacturer |
Life Time | 3-5 year |
Weight | 300-1000g/m² |
Bese Fabric | Polyester |
Fabric Count | 18*12-23*23yarn/sq.inch |
Thickness | 0.3- 0.7mm |
Roll Width (Max) | 3.2m |
Roll Length (Max) | 20 - 800m |
Surface Finishing | PVC |
Tensile Strength-Warp | 500N/5cm |
Tensile Strength-Weft | 500N/5cm |
Coating Adhesiion | 50N/5cm |
Temp Resistance | -30 to +70℃ |
Fire Retardent | B1,B2 Level |
Treatment | UV treated; Acrylic Lacquered |
Printing Compatibility | Printing Ready |
Update Time | Oct 4,2024 |
Detail Information
-
Tufflex-Tarp Fabric
Used as equipment cover, heavy duty tarpaulin cover, ground cover, growth cover, camouflage tarp cover, BBQ grill cover, patio furniture cover, fire retardant cover, hay tarp cover, insulated protective cover, gym floor cover, specialty cover, and other protective tarpaulin cover applications. - Their technical properties such as their excellent weldability and resistance to ageing convince all along the line. Large and small goods are perfectly covered.
Features:
MATERIAL DESCRIPTION | ||||||
---|---|---|---|---|---|---|
ITEM | UNIT | RESULT | TEST STANDARD | |||
Weight (+/-3%) | g/m² | 300 | 500 | 650 | 1000 | DIN EN ISO 2286-2 |
Bese Fabric | Type | Polyester | Polyester | Polyester | Polyester | DIN 60001 |
Yarn | Denier | 200*300 | 300*500 | 1000*1000 | 1000*1000 | DIN EN ISO 2060 |
Fabric Count | yarn/sq.inch | 18*12 | 18*12 | 20*20 | 23*23 | DIN EN 1049-2 |
Thickness | mm | 0.3 | 0.5 | 0.5 | 0.7 | - |
Roll Width (Max) | m | 3.2/5.1 | 3.2 | 3.2 | 3.2 | - |
Roll Length (Max) | m | 20 - 800 | 20 - 800 | 20 - 800 | 20 - 800 | - |
Surface Finishing | Material | PVC | PVC | PVC | PVC | |
Tensile Strength-Warp | N/5cm | 500 | 500 | 2600 | 3500 | DIN53354 |
Tensile Strength-Weft | N/5cm | 500 | 500 | 2400 | 3400 | DIN53354 |
Tear Strength-Warp | N/5cm | 150 | 150 | 350 | 350 | DIN53354 |
Tear Strength--Weft | N/5cm | 150 | 150 | 300 | 320 | DIN53363 |
Coating Adhesiion | N/5cm | 50 | 50 | 100 | 90 | DIN53363 |
Temp Resistance | ℃ | -30 to +70 | -30 to +70 | -30 to +70 | -30 to +70 | DIN EN 1876-2 |
Fire Retardent | B1,B2 level is optional upon request | |||||
Treatment | UV treated; Acrylic Lacquered upon request. | |||||
Color | 16 standard color, and can be customized. | |||||
Printing Compatibility | Printing Ready | |||||
Temp Resistance | Special treatment to use under -40℃ (optional) | |||||
Note: The technical specifications contained herein are believed to be reliable, but no representations, guarantees or warranties of any kind are made regarding their accuracy or suitability of the material for particular applications. |
Features:
- Excellent UV-protection
- Hign Tenacity Strength
- Anti Mildew
- Crack Resistant
- Customized FR Standard
- REACH Regulations Standard
- Anti cold crack
Colors Available:
-
Black
-
White
-
Red
-
Orange
-
Dark Green
-
Dark Red
-
Blue
-
Grey
-
Green
Applications:
-
Awning & Cover
The perfect awning can add beauty and shade to any venue. -
PVC Tents
Requently used in outdoor and long-life products. -
Carpark Cover
Easier and more stylish than ever thanks to the high-quality
Downloads:
- Tufflex-Tarp Fabric300> Download
- Tufflex-Tarp Fabric500> Download
- Tufflex-Tarp Fabric650> Download
- Tufflex-Tarp Fabric1000> Download
