Tufflex-Tarp Fabric

Tufflex-Tarp Fabric

Tufflex-Tarp Fabric
Tufflex-Tarp FabricTufflex-Tarp Fabric

Tufflex-Tarp Fabric

CategoriesPVC Coated Fabric
BrandTAIMEI Tarpaulin Shade Fabric Manufacturer
Life Time3-5 year
Weight300-1000g/m²
Bese FabricPolyester
Fabric Count18*12-23*23yarn/sq.inch
Thickness0.3- 0.7mm
Roll Width (Max)3.2m
Roll Length (Max)20 - 800m
Surface FinishingPVC
Tensile Strength-Warp500N/5cm
Tensile Strength-Weft500N/5cm
Coating Adhesiion50N/5cm
Temp Resistance-30 to +70℃
Fire RetardentB1,B2 Level
TreatmentUV treated; Acrylic Lacquered
Printing CompatibilityPrinting Ready
Update TimeMar 19,2024
Detail Information

Tufflex-Tarp Fabric

Used as equipment cover, heavy duty tarpaulin cover, ground cover, growth cover, camouflage tarp cover, BBQ grill cover, patio furniture cover, fire retardant cover, hay tarp cover, insulated protective cover, gym floor cover, specialty cover, and other protective tarpaulin cover applications.

Their technical properties such as their excellent weldability and resistance to ageing convince all along the line. Large and small goods are perfectly covered.

Features:

MATERIAL DESCRIPTION
ITEM UNIT RESULT TEST STANDARD
Weight (+/-3%) g/m² 300 500 650 1000 DIN EN ISO 2286-2
Bese Fabric Type Polyester Polyester Polyester Polyester DIN 60001
Yarn Denier 200*300 300*500 1000*1000 1000*1000 DIN EN ISO 2060
Fabric Count yarn/sq.inch 18*12 18*12 20*20 23*23 DIN EN 1049-2
Thickness mm 0.3 0.5 0.5 0.7 -
Roll Width (Max) m 3.2/5.1 3.2 3.2 3.2 -
Roll Length (Max) m 20 - 800 20 - 800 20 - 800 20 - 800 -
Surface Finishing Material PVC PVC PVC PVC
Tensile Strength-Warp N/5cm 500 500 2600 3500 DIN53354
Tensile Strength-Weft N/5cm 500 500 2400 3400 DIN53354
Tear Strength-Warp N/5cm 150 150 350 350 DIN53354
Tear Strength--Weft N/5cm 150 150 300 320 DIN53363
Coating Adhesiion N/5cm 50 50 100 90 DIN53363
Temp Resistance -30 to +70 -30 to +70 -30 to +70 -30 to +70 DIN EN 1876-2
Fire Retardent B1,B2 level is optional upon request
Treatment UV treated; Acrylic Lacquered upon request.
Color 16 standard color, and can be customized.
Printing Compatibility Printing Ready
Temp Resistance Special treatment to use under -40℃ (optional)
Note: The technical specifications contained herein are believed to be reliable, but no representations, guarantees or warranties of any kind are made regarding their accuracy or suitability of the material for particular applications.


Features:

  • Excellent UV-protection
  • Hign Tenacity Strength
  • Anti Mildew
  • Crack Resistant
  • Customized FR Standard
  • REACH Regulations Standard
  • Anti cold crack

Colors Available:

  • Black

  • White

  • Red

  • Orange

  • Dark Green

  • Dark Red

  • Blue

  • Grey

  • Green



Applications:

  • Awning & Cover

    The perfect awning can add beauty and shade to any venue.
  • PVC Tents

    Requently used in outdoor and long-life products.
  • Carpark Cover

    Easier and more stylish than ever thanks to the high-quality
