Woven Fabric Laminated Reflective Aluminium Foil

Woven Fabric Laminated Reflective Aluminium Foil

Woven Fabric Laminated Reflective Aluminium Foil

Woven Fabric Laminated Reflective Aluminium Foil

CategoriesPE Woven Fabric
BrandTAIMEI Tarpaulin Shade Fabric Manufacturer
ModelWF-P014
MaterialPE Woven Fabric
CoatingAluminum Film
ApplicationRoofing Underlay
Basis Weight105gsm
Water Vapor Transmission Rate1.15 ng/N.s
Tensile Strength -Machine Direction240 N/25mm
Tensile Strength -Cross Direction240 N/25mm
Burst Strength250N/cm2
Dimensional StabilityLess than 0.5%
Update TimeOct 4,2024
Detail Information

Introduction

Plastuf aluminum foil woven fabric is designed to function as cost effective radiant barrier and vapor barrier materials in variety of places, such as commercial buildings, gyms, warehouses, supermarkets, poultry houses, and more. It can also be used as the liner material in a container to offer efficient insulation performance.

Approximately 75% heat in the air is transmitted through radiation. Most materials used on buildings absorb the radiant heat and then re-radiate it. This results in higher room temperature than outside temperature in summer and lower in winter. Hence, most air conditioning systems are constantly working in residential and official as well as industrial buildings, which cost much. However, Plastuf aluminum foil woven fabric is able to reflect up to 97% radiant heat, so it is an ideal material to offer insulation against heat and moisture vapor. Therefore, when it is used as a building material, it effectively improves insulation system performance, and keeps the room cool in summer and warm in winter.



Product List:

Item Code Composition
FPE100 Aluminum foil in 7 microns thickness + Polyethylene adhesive + HDPE woven fabric
FPEV115 Aluminum foil in 7 microns thickness + Polyethylene bonding agent + HDPE Woven Fabric + PE coating
FPEF150 Aluminum foil in 7 microns thickness + Polyethylene bonding agent + HDPE woven Fabric + PE adhesive + Aluminum foil in 7 microns thickness
MPE100 MPET in 8 microns thickness + PE adhesive + HDPE Woven fabric
FG710P Aluminum foil in 7 microns + Polyethylene adhesive + Fiberglass cloth
FG1808P Aluminum foil in 18 microns + Polyethylene adhesive + Fiberglass woven cloth

FPE100 Single Sided Aluminum Fabric


Typical Physical Properties
Physical Property Value (Metric) Test Method
Basis Weight 105gsm Scale
Water Vapor Transmission Rate 1.15 ng/N.s ASTM E96, Procedure A
Tensile Strength -Machine Direction 240 N/25mm ASTM D828
Tensile Strength -Cross Direction 240 N/25mm ASTM D828
Burst Strength 250N/cm2 ASTM D774
Dimensional Stability Less than 0.5% ASTM D1204 @ 150F (65℃ )
Reflectivity of foil surface 97% --

Available Roll Width: 1.20m, 1.25m, 1.50m

FPEV115 Single Sided Foil Woven

Typical Physical Property

Physical Property Value (Metric) Test Method
Basis Weight 115 gsm Scale
Water Vapor Transmission Rate 1.15 ng/N.s ASTM E96, Procedure A
Tensile Strength -Machine Direction 250 N/25mm ASTM D828
Tensile Strength -Cross Direction 250 N/25mm ASTM D828
Burst Strength 260 N/cm2 ASTM D774
Dimensional Stability Less than 0.5% ASTM D1204 @ 150F (65℃ )
Reflectivity of foil surface 97% --
Available Roll Width: 1.20m, 1.25m, 1.50m

FPEF150 Double Sided Aluminum Woven Cloth

Typical Physical Property

Physical Property Value (Metric) Test Method
Basis Weight 150gsm5.75 ng/N.s Scale
Water Vapor Transmission Rate ASTM E96, Procedure A
Tensile Strength -Machine Direction 350 N/25mm ASTM D828
Tensile Strength -Cross Direction 350 N/25mm ASTM D828
Burst Strength 315 N/cm2 ASTM D774
Temperature Resistance Remains Flexible No Delamination ASTM C1263
- 29 ℃/+66 ℃
Dimensional Stability Less than 0.5% ASTM D1204 @ 150F (65C)
Reflectivity 97% --
Available Roll Width: 1.20m, 1.25m, 1.30m, 1.50m

MPE100 Single Sided MPET Woven

Typical Physical Property

Physical Property Value (Metric) Test Method
Basis Weight 100gsm Scale
Tensile Strength -Machine Direction 260 N/25mm ASTM D828
Tensile Strength -Cross Direction 260 N/25mm ASTM D828
Burst Strength 250 N/cm2 ASTM D774
Dimensional Stability Less than 0.5% ASTM D1204 @ 150F (65℃ )

Available Roll Width: 1.20m, 1.25m, 1.30m, 1.5m.

FG710P Foil Fiberglass Cloth Laminate

Construction

Facing Composition Description Value (Metric)
Foil Aluminum 7 micron
Adhesive Polyethylene 40 micron
Fiberglass Cloth 12x10 mesh/cm 100 gsm
Typical Physical Property
Physical Property Value (Metric) Test Method
Basis Weight 160 gsm Scale
Water Vapor Transmission Rate 5.75 ng/N.s ASTM E96, Procedure A
Tensile Strength -Machine Direction 315 N/25mm ASTM D828
Tensile Strength -Cross Direction 315 N/25mm ASTM D828
Burst Strength 130 N/cm2 ASTM D774
Low Temperature Resistance Remains Flexible No Delamination ASTM D1790 4 hrs @-40 ℉ (- 40℃)
High Temperature Resistance Remains Flexible No Delamination ASTM D1790 4 hrs @ +240 ℉ (+116℃)
Reflectivity of foil surface 97% --

Available Roll Width: 1.0m, 1.2m

FG1808P Aluminum Fiberglass Fabric Laminate

Construction

Facing Composition Description Value (Metric)
Foil Aluminum 18 micron
Binder PE 30 micron
Fiberglass 8x8 mesh/cm 95 gsm
Typical Physical Property
Physical Property Value (Metric) Test Method
Basis Weight 170 gsm Scale
Tensile Strength -Machine Direction 250 N/25mm ASTM D828
Tensile Strength -Cross Direction 150 N/25mm ASTM D828
Burst Strength 120 N/cm2 ASTM D774
Temperature Resistance Remains Flexible No Delamination ASTM C1263
- 30 ℃/+100 ℃
Dimensional Stability Less than 0.5% ASTM D1204 @ 150F (65C)
Reflectivity of foil surface 97% --

Available Roll Width: 1.0m, 1.2m



Product Features:

  • 1. The aluminum foil woven fabric is environmental friendly. It contains no hazardous chemicals or harmful materials that cause itching or respiratory problems. Also, it emits no formaldehyde or volatile organic compounds, ensuring healthy indoor environment.
    2. As compared with other types of aluminium foil insulation material, this product offers higher tensile strength, and higher tearing resistance.
    3. It is anti abrasion, anti aging, light weight, and flexible and easy to handle.
    4. It is a superb low cost, waterproof type building material.
    5. Coming in woven fabric form, the product can be sewed together easily and conveniently installed on long span buildings.

    Due to high quality and cost effectiveness, our aluminium foil woven fabric is highly recognized around the world, and has been exported to Europe, North America, South America, Asia and Africa.

    As an eco-friendly heat insulation material, our aluminum foil woven fabric has found applications in many fields. For instance, it can be used as the sandwich material for ice bags, and can also be simply placed on rooftop to offer waterproof and heat insulation functions. It can also be used in the manufacturing of the beach mat, moisture-proof pad, and the packaging material for home appliance, precision instrument, high grade chinaware, etc. Additionally, the product can also be made into variety of shapes to function as the sun shade for automobiles, air conditioner outdoor units, and motorcycles.

Colors Available:

  • Black

  • White
